EC135 to EC145

Author: Excerpts... Date: 1/5/2025 4:12:36 PM +9/-3 Show Orig. Msg (this window) Or In New Window

The BK117 C-2 AFCS basic version is connected to the 28 V DC power system and consists of:

-- Two dual electronic modules (Autopilot Modules -- APM) which acquire helicopter angles and rates, compute AFCS control laws (basic stabilization and upper modes functions) and transmit them to the actuators. A built-in test is provided for preflight check. The autopilot modules are located inside the PELICAN rack of the helicopter.

-- Self-monitored duplex series actuators of the smart electro-mechanical (SEMA) type for pitch and roll axes. Simplex SEMA is used for the directional axis.
